N64 2x Firmware Update Tutorial
- Download the software tools from the official website(www.bitfunx.com)
- Run exe file，Click OK to skip the warning.
3、N64 2X Updater Program instruction
3.1 Firmware update
(1) Click the Update button
(2) According to the instructions，hold the button first and then plug into your win10 PC with micro usb.
(3) After the connection, select the latest version of firmware and click the update button to update the firmware
(4) Wait until the progress bar is complete and the update success message pops up on the computer.
3.2 One-click repair
Note: This feature is only available for the N64 console in the Pal region
- Use micro USB to connect the HDMI converter to the computer(win10 PC)
(2) After the connection is successful, the serial port name “COM24″(name is not fixed) will be displayed in the software.
(3)Click Open button to load flash chip and all parameters enter editable state.
(3) Click on the Tools menu and select “Fix N64 PAL Wobble“
Click on the Tools menu and select “Brazil PAL-M“(Fix image compatibility issues)
(4) Click the “Save Settings” button to complete the update
3.3 Screen Position\Color\Fliter settings
NOTE：this function needs to be set according to the game screen when the console is working
(1) Use micro USB to connect the HDMI converter to the computer(win10 PC)
(2) After the connection is successful, the serial port name “COM24″(name is not fixed) will be displayed in the software.
(3)Click Open button to load flash chip and all parameters enter editable state.
(4) E.g: choose”Compostie 2x with smoothing”mode
Move the screen up:
Move the screen down：
Reduce picture contrast：
Increase YSFM：
(5) After the setup is complete, Click the “Save settings”. then exit the program
